#28024feat(editor): Refactor role provisioning to two-dropdown layout

SSO role provisioning split into two dropdowns

SSO role provisioning split into two dropdowns
CS
cstuncsik
·Apr 10, 2026

n8n users configuring SSO can now choose role assignment and mapping method as separate steps, with expression validation that catches syntax errors before saving.

SSO role provisioning settings in n8n have been reorganized. Instead of one dropdown that required users to parse role assignment and mapping method from a single list, two separate dropdowns now break the decision into clear steps: first choose how roles are assigned (manually in n8n, instance roles via SSO, or both instance and project roles via SSO), then — when appropriate — choose how those claims are mapped (directly from the IdP or via rules defined in n8n).

Expression inputs now validate syntax in real time. When an expression is invalid, the border turns red and text appears in red; valid expressions show a green border. This prevents configuration errors from being saved and simplifies troubleshooting.

The change is part of a broader initiative to improve n8n's SSO configuration experience. The two-dropdown layout matches the approved Figma design, and the expression validation addresses a gap where users could enter malformed expressions without immediate feedback.

View Original GitHub Description

Summary

Refactors the single "User role provisioning" dropdown into a two-dropdown layout matching the approved Figma design. This is PR 4 of 4 for IAM-397, tracked as IAM-521.

What this PR does:

  • Splits the single "User role provisioning" dropdown into two separate selects:
    1. Role assignment — Assigned manually in n8n / Instance roles via SSO / Instance and project roles via SSO
    2. Role mapping method (conditional, hidden when manual) — Map rules on your IdP / Map rules inside n8n
  • Dropdown options show rich content (title + description) in the popup
  • Shows an info callout when "Map rules on your IdP" is selected
  • Shows only instance rule editor when "Instance roles via SSO" + "Map rules inside n8n" is selected
  • Shows both instance + project rule editors when "Instance and project roles via SSO" + "Map rules inside n8n" is selected
  • Adds scopesUseExpressionMapping to the frontend ProvisioningConfig type
  • Uses a project-rules-presence heuristic to recover the first dropdown's value when loading config with expression mapping active
  • Removes N8N_ENV_FEAT_ROLE_MAPPING_RULES feature flag gating
  • Adds comprehensive tests for the conversion logic and heuristic

Frontend-only change — backend already has scopesUseExpressionMapping field.

How to test manually

  1. Go to Settings → SSO → configure SAML or OIDC
  2. In the "Role assignment" card, verify:
    • "Assigned manually in n8n" — no second dropdown, no rule editor, no bottom border
    • "Instance roles via SSO" — second dropdown appears ("Role mapping method")
      • "Map rules on your IdP" → info callout shown
      • "Map rules inside n8n" → instance rule editor only (no project section)
    • "Instance and project roles via SSO" — second dropdown appears
      • "Map rules on your IdP" → info callout shown
      • "Map rules inside n8n" → both instance + project rule editors shown
  3. Click into each dropdown — options should show bold title + grey description text
  4. Verify selects are 280px wide, medium height, aligned with copy inputs
  5. Save settings and reload — dropdowns should restore to the correct values
  6. Test with expression mapping + only instance rules saved → should show "Instance roles via SSO"
  7. Test with expression mapping + project rules saved → should show "Instance and project roles via SSO"

Key decisions for reviewers

  • Two dropdowns map to three boolean flags — scopesProvisionInstanceRole, scopesProvisionProjectRoles, scopesUseExpressionMapping. When expression mapping is active, both scopes booleans are false (mutually exclusive backend code paths). See IAM-521 ticket for the full state matrix.
  • Project rules heuristic — When scopesUseExpressionMapping=true, both scopes booleans are false, making "instance" vs "instance+project" indistinguishable from config alone. The frontend checks whether project-type rules exist in the DB to infer the user's intent. Documented in useUserRoleProvisioningForm.ts and the IAM-521 ticket.
  • Legacy formValue computed — The old single-value type (UserRoleProvisioningSetting) is kept as a computed for backward compatibility with ConfirmProvisioningDialog and telemetry. The two-dropdown refs (roleAssignment, mappingMethod) are the source of truth.
  • RoleMappingRuleEditor.showProjectRules prop — Controls whether the project rules section renders, driven by roleAssignment === 'instance_and_project' from the parent form.

Related Linear tickets, Github issues, and Community forum posts

https://linear.app/n8n/issue/IAM-521 https://linear.app/n8n/issue/IAM-397

Review / Merge checklist

  • PR title and summary are descriptive. (conventions)
  • Docs updated or follow-up ticket created.
  • Tests included.
  • PR Labeled with release/backport (if the PR is an urgent fix that needs to be backported)
  • I have seen this code, I have run this code, and I take responsibility for this code.
